Model NoGF-KSW-48ADimensions 504(L)×374(W)×134(H) mmWeight (kg)4.8-5.2kgCable entrance ports12Splice traycapacity24fMax splice capacity96fAdaptor48pcs SC/FCDrop cable48pcsIP levelIP55Operation temperature-40~+60℃Atmospheric pressure 70~106Kpa
Model NoGF-KSW-16ADimensions 326(L)×277.5(W)×124(H) mmWeight (kg)3.0-3.5kgCable entrance ports3pcs of Φ10-15 optical cable ports, 18pcs of 8 figure soft cable portsSplice traycapacity24fMax splice capacity24fSplitter2*1:4 or 2*1:8 or 1*1:16 cassette PLCIP levelIP55Operation temperatur
Model NO.GF-KSW-8BSize(mm)195mm×230mm×75mmGross Weight(kgs)2-2.5 kgsNO of Cable Entry3in(φ9mm)NO of Drop Cable8pcs of 2*3 mm soft cable or φ5mm round cableAdaptor8pcs of SC/APCSplitter1*8 Mini type splitter SC/APC G657A2Fiber length Input 1.5m, output 1mwith n
