    4 Ports EPON OLT

    4 PON Ports EPON OLT provides 4GE(copper) and 4*SFP/SFP+ slots independent interface for uplink, and 4*EPON OLT ports for downlink. It can support overall 256 ONU's with 64 ONU's per PON port.


    It is a 1U height 19 inch rack mount product. The features of the OLT are small, convenient, flexible, easy to deploy and high performance. It is appropriate to be deployed in compact room environment. The OLT can be used for "Triple-Play", VPN, IP Camera, Enterprise LAN and Internet service provider applications.

  • Contact Us
  • Specifications:

    ItemGW-1004E
    ChassisRack1U 19 inch standard box


    1G/10G

    Uplink Port
    Qty8
    Copper 10/100/1000M auto-negotiation4
    SFP 1GE4
    SFP+ 10GE


    EPON Port

    Qty4
    Physical InterfaceSFP Slot
    Connector TypePX20+
    Max splitting ratio1:64
    Management Ports1*10/100BASE-T out-band port, 1*CONSOLE port


    PON Port Specification (PX20+ module)

    Transmission Distance20KM
    EPON port speedUpstream 1.25G
    Downstream 1.25G
    WavelengthTX 1490nm, RX 1310nm
    ConnectorSC/UPC
